Parts
308647T 21
Model 244734
* Included in Fluid Diaphragm Repair Kit 238747
†
Included in Cartridge Repair Kit
248098
+ Included in Air-Operated Conversion Kit 238749
Included in Diaphragm Housing Repair Kit 16P596
Ref. Part Description Qty.
1 * ACTUATOR 1
2+ 191584 HOUSING ADAPTER 1
3† 191577 NUT, spring retainer 1
4 197952 HOUSING, base 1
5† 191579 HOUSING, valve; sst 1
6+ 191585 ROD, piston 1
7 * PLUNGER, spring 1
8 191583 PLATE, backing 1
9 113623 BASE HOUSING SCREW, cap,
socket-head; M10 x 1.5 x 70
4
11+ 114104 SCREW, machine 12
12 * DIAPHRAGM, regulator; PTE
cream colored
1
13 * DIAPHRAGM, regulator; PTFE
white
1
14†
191914 SEAT, valve
1
15† 113651 O-RING, packing; PTFE 1
16† 15D092 BALL 1
17* 109213 O-RING, packing; PTFE 025 1
18† 107079 O-RING, packing; PTFE 019 1
19 * O-RING, packing; PTFE 013 1
20† 109450 O-RING, packing; PTFE 016 1
21† 111858 SPRING, compression 1
22+ 160062 SPRING, stabilizing 1
25 113654 GAUGE, pressure (for Models
238894 and 248090)
1
28+ ---- COVER, diaphragm 1
29+ ---- HOUSING, diaphragm 1
30+ 100326 SCREW, machine 1
36+ 192194 WASHER, support 1
37+ 180979 DIAPHRAGM; nylon 1
38 238896 PLUG, EZ Flush (includes Ref. 39) 1
39 107509 O-RING, packing; PTFE 007 1
40 198171 FITTING, elbow 1
41 198241 PLUG, pressure 2
42 111457 PACKING, o-ring; PTFE 012 2
Ref. Part Description Qty.
To Next Page
