Graco 24F150 Instruction & Parts Manual

Parts
3A0732B 31
Displacement Pump Parts
Part No. 24G701, Plated Steel
Part No. 24G702, Stainless Steel
‡ Included in Pump Lower Rebuild Kit. Order Kit 24H006 for Pump 24G701, or Kit 24G705 for Pump 24G702.
❖ Included in Intake Check Valve Kit 246429.
Ref. Description 24G701 24G702 Qty
102‡ BUTTON, plug --- --- 1
103 NUT, packing; plated steel 193047
1
NUT, packing; sst
24H161 1
104‡ O-RING; buna-N; 1.262 in. (32.05 mm) OD --- --- 1
105 CYLINDER, pump 243176 24G706 1
106‡
V-PACKING, throat; V-Max
™
UHMWPE
--- --- 3
107‡ O-RING; PTFE; 1.254 in. (31.85 mm) OD --- --- 1
109❖ GUIDE, ball 15C011 15C011 1
110 VALVE, intake housing; plated steel 15B611
1
VALVE, intake housing; sst
24H007 1
111‡
❖
O-RING; PTFE; 0.941 in. (23.90 mm) OD --- --- 1
112‡ GLAND, female, throat; acetal --- --- 1
113‡ V-PACKING, throat; leather --- --- 2
114‡ GLAND, male, throat; acetal --- --- 1
116‡
❖
BALL, intake; sst; 0.500 in. (13 mm) dia. 105445 105445 1
117❖ SEAT, carbide 15A968 15A968 1
119
KIT, rod, displacement; Chromex
™
; includes item 124, and items 18 and 19
on page 25
24G703 24G704 1
120‡ BALL, piston; sst; 0.3125 in. (7.94 mm) dia. 105444 105444 1
121‡ GLAND, male, piston; plated steel ---
1
GLAND, male, piston; sst
--- 1
122‡ GLAND, female, piston; plated steel ---
1
GLAND, female, piston; sst
--- 1
123‡ WIPER, piston --- --- 1
124 VALVE, piston; plated steel Order
item 119
1
VALVE, piston; sst
Order
item 119
1
125‡ V-PACKING, piston; leather --- --- 2
126‡
V-PACKING, piston; V-Max
™
UHMWPE
--- --- 3
