Setup
311764D 9
Touch Up Hopper Attachment
1. Connect air hose to sprayer.
2. Connect air hose to gun.
3. Slide hopper on top of gun, and tighten clamp.
4. Install spray nozzle, page 11.
5. Fill Touch-up hopper with pre-mixed texture. See
Mixing Material, page 10.
6. Turn selector knob to HOPPER GUN.
7. Open gun air valve.
8. Turn power switch ON.
9. To achieve uniform spray pattern, adjust air valve
and flow adjustment nut on gun. If you do not
achieve the desired spray pattern, change nozzles
(see page 11).
The Hose Plug must be
securely fastened to bottom
of gun when using the Touch
Up Hopper. Gun plug must
be removed from top of gun.
CAUTION
Failure to change selector switch to Hopper Gun when
using hopper gun will damage pump hose.
ti8701a
ti8534a
ti8706a
ti2559a
ti8728a
ti8528a
ti8711a
ti8532a
