Fuse Replacement
22 310824D
Fuse Replacement
Removal
1. Relieve pressure, page 8. Disconnect power cord
from outlet.
2. Remove two screws (30) and shroud (29).
3. Remove fuse from control board.
4. Remove spare fuse from motor.
Installation
1. Replace fuse on control board with spare fuse.
2. Install shroud (29) and two screws (30).
Replaceable Fuse
ti9134b
Spare Fuse
(included n
110V and 120
models only)
