Graco 395 - Page 15

15309674
Fig. 11
ti2478a
50
A
12
58
E
D
C
B
L1L2
Heat from inductor coil of filter board may destroy wire
insulation that comes in contact with it. Exposed wires
could cause shorts and component damage. Bundle
and tie all loose wires so none lay in contact with
inductor coil of filter board.
CAUTION
Potentiometer
Digital Display
Filter Board
Inductor Coil
Brown
Brown
Black
ON/OFF
Switch
To Power
Plug
From Motor
Green
2 x White
Black /
white (–)
Black
Blue
Blue
Red (+)
Transducer
30
19
38
37
49
47
20
6
TP1
TP2
11
37a
ti2478a
