Installation
General Information
NOTE:
D Reference numbers and letters in parentheses in
the text refer to the callouts in Figure 1 and the
parts drawing.
D Use Genuine Graco Parts and Accessories, avail-
able from your Graco distributor.
Grounding
WARNING
FIRE AND EXPLOSION HAZARD
Before operating the pump, ground the
system as explained below. Also read
the section FIRE AND EXPLOSION
HAZARD on page 3.
1. Pump: use a ground wire and clamp as shown in
your separate pump manual.
2. Air or hydraulic hoses: use only electrically con-
ductive hoses.
3. Fluid hoses: use only electrically conductive fluid
hoses.
4. Air compressor or hydraulic supply: follow the
manufacturer’s recommendations.
5. Spray gun: ground by connecting the gun to a
properly grounded fluid hose and pump.
6. Fluid supply container: follow your local code.
7. Object being sprayed: follow your local code.
8. Solvent pails used when flushing: follow your local
code. Use only metal pails, which are conductive,
placed on a grounded surface. Do not place the
pail on a nonconductive surface, such as paper or
cardboard, which interrupts the grounding continu-
ity.
9. To maintain grounding continuity when flushing or
relieving pressure, hold a metal part of the spray
gun firmly to the side of a grounded metal pail,
then trigger the gun.
