308443 29
Parts
Seat Parts List (Matrix Column 4)
Digit
Ref.
No.
Part No. Description Qty
2 201* 188604 SEAT; acetal 4
202* 109205 O-RING;  8
3 201* 188707 SEAT; 316 stainless steel 4
202* 109205 O-RING;  8
4 201* 188708 SEAT; 17-4 stainless steel 4
202* 109205 O-RING;  8
5 201* 188711 SEAT; Hytrel 4
202 None Not Used 0
6 201* 191595 SEAT; Santoprene 4
202* 114229 O-RING;  encap-
sulated
8
7 201* 15B275 SEAT; Buna–N 4
202 None Not used 0
8 201* 15B633 SEAT; Viton 4
202 None Not Used 0
9 201* 189722 SEAT; polypropylene 4
202* 109205 O-RING;  8
A 201* 189723 SEAT; Kynar 4
202* 109205 O-RING;  8
G 201* 194211 SEAT; Geolast 4
202* 109205 O-RING;  8
Ball Parts List (Matrix Column 5)
Digit
Ref.
No. Part No. Description Qty
1 301* 112088 BALL;  4
2 301* 112254 BALL; acetal 4
3 301* 103869 BALL; 316 stainless steel 4
4 301* 102973 BALL; 440C stainless
steel
4
5 301* 112089 BALL; Hytrel 4
6 301* 112092 BALL; Santoprene 4
7 301* 15B488 BALL; buna-N 4
8 301* 15B487 BALL; Viton 4
G 301* 114751 BALL; Geolast 4
Digit
Ref.
No. Part No. Description Qty
1 401* 188606 DIAPHRAGM, backup;
Hytrel
2
402* 112181 PACKING, u-cup; nitrile 2
403* 188605 DIAPHRAGM;  2
5 401* 188606 DIAPHRAGM; Hytrel 2
402* 112181 PACKING, u-cup; nitrile 2
6 401* 188857 DIAPHRAGM;
Santoprene
2
402* 112181 PACKING, u-cup; nitrile 2
7 401* 15B499 DIAPHRAGM; buna-N 2
402* 112181 PACKING, u-cup; nitrile 2
8 401* 15B500 DIAPHRAGM; Viton 2
402* 112181 PACKING, u-cup; nitrile 2
G 401* 194212 DIAPHRAGM; Geolast 2
402* 112181 PACKING, u-cup; nitrile 2
PTFE
PTFE
PTFE
PTFE
PTFE
PTFE
PTFE
PTFE
PTFE
