34 308443
Technical Data
Maximum fluid working pressure. . . . . . . . . . . . . . . . .120 psi
(0.8 MPa, 8 bar)
Air pressure operating range. . . . . . . . . . . . . . . 20 to 120 psi
(0.14 to 0.8 MPa, 1.4 to 8 bar)
Maximum air consumption . . . . . . . . . . . . . . . . . . . . 60 scfm
Air consumption at 70 psi/20 gpm. . . . . . 20 scfm (see chart)
Maximum free-flow delivery . . . . . . . . . . 42 gpm (159 l/min)
Maximum pump speed . . . . . . . . . . . . . . . . . . . . . . 276 cpm
Gallons (Liters) per cycle . . . . . . . . . . . . . . . . . . . 0.15 (0.57)
Maximum suction lift . . . . . . . . . . . . 18 ft (5.48 m) wet or dry
Maximum size pumpable solids . . . . . . . . . . 1/8 in. (3.2 mm)
* Maximum Noise Level at 100 psi, 50cpm . . . . . . . . 89 dBa
Sound Power Level. . . . . . . . . . . . . . . . . . . . . . . . 100 dBa
* Noise Level at 70 psi and 50 cycles/min: . . . . . . . .78 dBa
Maximum operating temperature . . . . . . . . 150 °F (65.5 °C)
Air inlet size. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1/2 npt(f)
Fluid inlet size . . . . . . . . . . . . . . . . . . 1” Raised Face Flange
Fluid outlet size . . . . . . . . . . . . . . . . . 1” Raised Face Flange
Wetted parts . . . . . . . Vary by Model. See pages 29 and 31.
Non-wetted external partsaluminum, 302, 316 stainless steel,
polyester (labels)
Weight (approximate) . . . . . . . . . . . . . Polypropylene Models
. . . . . . . . . . . . with aluminum center section : 19 lb (8.6 kg)
. . . . . . . . with stainless steel center section : 32 lb (14.6 kg)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Acetal Models
. . . . . . . . . . . . . with aluminum center section : 22 lb (10 kg)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . PVDF Models
. . . . . . . . . . . . with aluminum center section: 25 lb (11.3 kg)
. . . . . . . . . . with stainless steel center section: 35 lb (16 kg)
Geolast
®
and Santoprene
®
are registered trademarks of the
Monsanto Co.
Loctite
®
is a registered trademark of the Loctite Corporation.
* Noise levels measured with the pump mounted on the
floor, using Rubber Foot Kit 236452. Sound power
measured per ISO Standard 9216.
