Graco DH230 User Manual

Component Identification
12 334558D
ProContractor Models (DH230)
2.
9.
1.
3.
bar/MPa
PSI
on
off
5.
6.
ti28398a
11.
4.
7.
8.
13.
15.
16.
10.
14.
OFF
50%
100%
1 Engine Controls
2 Hydraulic Oil Cap / Dipstick
3 Pressure Control
4 Hydraulic Pump Valve
5 Hose Reel Handle
6 Hose Reel Lock
7 Grounding Clamp
8 ProConnect
9 Inlet Strainer
10 Displacement Pump
11 Serial Number Tag
13 Gun Trigger Lock
14 Prime/Drain Valve
15 Easy Out™ Paint Filter
16 Hydraulic Oil Filter

Graco DH230 Specifications

General

Brand	Graco
Model	DH230
Category	Paint Sprayer
Language	English
