Graco DH230 User Manual

Technical Data
62 334558D
GH
™
200 Standard Series
US Metric
Maximum fluid working pressure 3300 psi 22.8 MPa, 228 bar
Hydraulic reservoir capacity 1.25 gallons 4.75 liters
Maximum hydraulic pressure 1855 psi 12.8 MPa,128 bar
Engine 160 cc (5.5 HP)
Maximum tip size 0.047
Maximum free-flow delivery 2.15 gpm 9.8 l/min
Hose connection 1/4 npsm (m)
Noise (dBa)
Maximum sound pressure 96 dBa
Maximum sound power 110 dBa
Inlet/Outlet Sizes
Fluid inlet size 1 5/16-12 UN-ZA
Fluid outlet size 3/8 npt (f)
Weight 160 lb. 73.4 kg
Width 24 in. 61 cm
Length 41 in. 104.1 cm
Height (Handle extended) 39.5 in. 100.3 cm
GH
™
230 Standard Series
US Metric
Maximum fluid working pressure 3300 psi 22.8 MPa, 228 bar
Hydraulic reservoir capacity 1.25 gallons 4.75 liters
Maximum hydraulic pressure 1855 psi 12.8 MPa,128 bar
Engine 200 cc (6.5 HP)
Maximum tip size 0.053
Maximum free-flow delivery 2.35 gpm 10.7 l/min
Hose connection 3/8 npsm (m)
Noise (dBa)
Maximum sound pressure 96 dBa
Maximum sound power 110 dBa
Inlet/Outlet Sizes
Fluid inlet size 1 5/16-12 UN-ZA
Fluid outlet size 3/8 npt (f)
Weight 168 lb. 75.6 kg
Width 24 in. 61 cm
Length 48 in. 121.92 cm
Height (Handle extended) 41.0 in. 104.1 cm
Height (Handle retracted) 33.0 in. 83.8 cm

Graco DH230 Specifications

General

Brand	Graco
Model	DH230
Category	Paint Sprayer
Language	English
