Graco DH230 User Manual

Models
334558D 3
Models
Electric Motor Kit Options
*Performance is limited when using electric motor vs internal combustion engine
OEM Kits
GH130
Model: Standard 120V Motor Kit
(Non CSA)
24W923 
24W924 
DH230
Model: Standard ProContractor
17G591 
GH200
Model: Standard ProContractor 120V Motor Kit
(Non CSA)
24W925 
24W926 
24W927 
24W928 
GH230
Model: Standard ProContractor 120V Motor Kit
(Non CSA)
120V ETL/CSA/UL
Motor Kit
24W929 
24W930 
24W931 
24W932 
24W933 
24W934 
GH300
Model: Standard ProContractor
24W935 
24W936 
Kit Number Sprayer Model Description
288474 GH130 120VAC, 60Hz, 20A, ETL/CSA/UL Approved
288473 GH130 120VAC, 60Hz, 15A
248950 GH200/DH230/GH230/GH300* 120VAC, 60Hz, 20A, ETL/CSA/UL Approved
248949 GH200/DH230/GH230/GH300* 120 VAC, 60Hz, 15A
24M668 GH200/DH230/GH230/GH300* 240VAC, 50Hz, 15A
Kit Number OEM Model Description
24W297 GH130 OEM 3300 psi (22.8 MPa, 228 bar) Maximum Working Pressure (psi)
24W298 GH200 OEM 3300 psi (22.8 MPa, 228 bar) Maximum Working Pressure (psi)
24W299 GH230/300 OEM 3330 psi (22.8 MPa, 228 bar) Maximum Working Pressure (psi)

Graco DH230 Specifications

General

Brand	Graco
Model	DH230
Category	Paint Sprayer
Language	English
