Spraying
12
332156D
Spraying
1.
Set pump v
a
lve ON.
2.
In
crease pressure enough to start hydraulic motor
stroking and allow fluid to circulate for 15
s
e
conds;
turn pressure down.
3.
T
urn
spray gun tri
gger safety OFF
.
4.
Adjust pressure to desir
e
d setting. Begin spraying.
5.
Rotate Lock Ring clockwise to set p
ressure.
ti7108a
ti71
10c
ti5403a
ti21
1
43a
ti71
1
0c
ti21062a
ti20968a
11
13
