Graco GH Series User Manual

Technical Data
332156D 21
GH933ES, GH933
US Metric
Sprayer
Hydraulic Pressure 2750 psi 190 bar
Hydraulic Reservoir Capacity 4.0 gallons 15.1 liters
Honda Motor 13 HP 9.7 KW
Vanguard Motor 14 HP 10.4 KW
Maximum Delivery 2.5 gpm 9.5 lpm
Maximum Pressure 7250 psi 500 bar
Maximum Tip Size
• 1 gun .065 in. 1.65 mm
Fluid Inlet 1.25 in. npt(m) 3.2 cm npt(f)
Fluid Outlet Pump 0.5 in. npt(f) 1.8 cm npt(f)
Fluid Outlet (with fitting as shipped) 0.5 in. npt(m) 1.8 cm npt(m)
Dimensions
Weight 438 lb 199 kg
Height 49 in. 124 cm
Width 28 in. 71 cm
Length 43 in. 109 cm
Sounds Levels*
Sound Pressure 91 dB(A)
Sound Power 106 dB(A)
*measured at maximum normal load conditions
Wetted Parts
Displacement Pump steel, nitralloy, tungsten, carbide, PTFE, leather,
polyethylene
Filter polyethylene, stainless steel
Miscellaneous
Graco-Approved Hydraulic Oil
169236 5 gallons 19 liters
207428 1 gallon 3.8 liters

Graco GH Series Specifications

General

Spray Tip Size	0.017 - 0.027 inches
Hose Length	50 feet
Weight	120 lbs
Power Source	Gasoline
Engine	Honda
Type	Airless Paint Sprayer
Flow Rate	0.6 GPM
Motor Type	4-Stroke
