Parts
2 311492F
Parts
GH833: Part No. 249767, 253473
Replacement Danger and Warning labels, tags, and cards
are available at no cost.
‡ Use on model 253473.
* Included in Hydraulic Motor Repair Kit 24Y566
FN Part No. Description Qty
7
* 120226 SCREW, hex hd, flange 4
36 287834 KIT, pump, displacement, includes
141
1
40
* 116554 WASHER, flat 1
42 15G501 SLEEVE, valve, hydr, motor 1
43 15G503 STOP, valve, hydraulic motor 1
44 15D256 SCREW, cap, sch 2
45 101947 BALL, bearing 2
46 15G270 YOKE, arm, hydraulic motor 2
48 105270 SCREW, shoulder, sch 4
52
* 287869 CYLINDER, hydraulic motor 1
53 287870 KIT, repair, packing, hydraulic,
includes 62
1
53a BEARING, piston 1
53b O-RING, piston 1
53c SEAL, piston, hydraulic motor 1
53d SEAL, rod 1
53e BEARING, rod 1
53f WIPER, rod 1
62
* 116084 PACKING, o-ring 2
63
* 15G559 HOUSING, hydraulic motor, lower 1
66
* 101970 PLUG, pipe 1
73
* 15G639 ADAPTER, hydraulic motor/pump 1
74
* 120202 SCREW, cap sch 3
75 288061 CAP, hydraulic head, includes 175 1
76 287868 PISTON, hydraulic 1
90
* 120138 SCREW, cap, socket head 3
91 120146 SPRING, compression 1
97
* 287841 TUBE 1
104
* 120065 FITTING, hydraulic 1
105
* 117607 FITTING, elbow std thd 1
106
* 117609 FITTING, tee, branch, str thd 1
121
* 116407 CLIP, hairpin 1
122 15G204 NUT, retaining 1
124 197340 COVER, coupler 1
125
* 244819 COUPLING, assembly 1
141 15H335 FITTING, nipple, 1 in. npt, includes
36
1
169
* 16U557 LABEL, front 1
170 15G878 LABEL, Graco logo 1
175*
15B063 LABEL, warning 1
163‡ 15H201 SHIELD, pump 1
164‡ 111235 SCREW, mach, pnh 1
165‡ 120317 NUT, wing 1
Item Description
HYDRAULIC INLET, 3/4 in. - 16 UNF 2A, 37° flared
lance
HYDRAULIC RETURN, 1-1/6 in. - 12 UN 2A, 37°
flared male
MOUNTING SLOT, 4X, 7/16 in. - 14 UNC 2B, flange
head, cap screw, 1-3/4 in. long recommended (Graco
PN 120226)
1 in. - 11-1/2 NPT Female
1-1/2 in. - 11-1/2 NPT Male
FN Part No. Description Qty
