Graco GH733 Instructions-Parts List

Parts
4 311492F
GH733: Part No. 24U326
Replacement Danger and Warning labels, tags, and
cards are available at no cost.
* Included in Hydraulic Motor Repair Kit 24Y566
FN Part No. Description Qty
1 16U773 BRACKET, mount pump, painted 1
2* 116554 WASHER, flat 1
3* C20019 SCREW, cap, socket head 1
4 111802 SCREW, cap, hex head 2
5 109570 WASHER, plain 2
6* 116084 PACKING, o-ring 2
7* 287869 KIT, repair, cylinder, hydraulic
(4GPM)
1
8* 15G559 HOUSING, hydraulic motor, lower 1
9 16U336 ROD, tie 3
10 101712 NUT, lock 3
11* 287868 KIT, repair, piston/rod, hydraulic 1
12 16U937 FITTING, tee, NTP, 1 X 3/4 X 3/8 1
13 157785 FITTING, swivel 1
14 245143 VALVE, pressure, bleed 1
21* 120138 SCREW, cap, socket head 3
23 L250C1 LOWER, xtreme, 250, NF, seal 1
24* 120202 SCREW, cap sch 3
25* 244819 COUPLING, assembly, 145-290 XT 1
26* 197340 COVER, coupler 1
27 244820 CLIP, hairpin (w/ lanyard) 1
29* 117607 FITTING, elbow std thd 1
30* 101970 PLUG, pipe hdls 1
31* 117609 FITTING, tee, branch, str thd 1
32* 120065 FITTING, hydraulic 1
34* 287841 TUBE, rigid, hydraulic 1
35 288061 CAP, hydraulic head, includes 38 1
36* 16U557 LABEL, brand 1
37* 15G878 LABEL, Graco logo 1
38*
 15B063 LABEL, warning, hot surface 1
39* 120226 SCREW, hex hd, flange 4
40*
 15H108 LABEL, pinch point 1
42 15G501 SLEEVE, valve, hydr, motor 1
43 15G503 STOP, valve, hydraulic motor 1
44 15D256 SCREW, cap, sch 2
45 101947 BALL, bearing 2
46 15G270 YOKE, arm, hydraulic motor 2
48 105270 SCREW, shoulder, sch 4
53 287870 KIT, repair, packing, hydraulic,
includes 6
1
53a BEARING, piston 1
53b O-RING, piston 1
53c SEAL, piston, hydraulic motor 1
53d SEAL, rod 1
53e BEARING, rod 1
53f WIPER, rod 1
91 120146 SRPING, compression 1
Item Description
HYDRAULIC INLET, 3/4 in. - 16 UNF 2A, 37° flared
male
HYDRAULIC RETURN, 1-1/6 in. - 12 UN 2A, 37°
flared male
MOUNTING SLOT, 4X, 7/16 in. - 14 UNC 2B, flange
head, cap screw, 1-3/4 in. long recommended (Graco
PN 120226)
1.0 in. NPT Female
0.75 in. NPS Female swivel (with fitting as shipped)
1.25 in. NPT Male
FN Part No. Description Qty
1
2
3
4
5
