Graco Glutton 400 Series - Page 21

307843 21
Service
Fig. 8
40r
40q
40h*
*40i
*40h
40m
40k
40b
*40g
*40f
40c
40d
40e
*40j
40a
43
40n
*72
42*
5h
40p REF
40h REF
5h
40p
40s
40p
40n
NOTES:
Torque to 2.2 to 3.7 ft-lb (3 to 5 NSm)
Press fit using 40 to 60 lb (18 to 27 kg) force
Lubricate with lithium-base grease
Apply medium strength sealant to threads.
Torque to 0.58 to 1.1 ft-lb (0.79 to 1.47
NSm)
Apply sealant to threads
2
1
3
4
5
1
2
3
3
3
3
3
3
4
1
5
0232
8
3
3
