Graco Glutton 400 Series - Filter, Regulator, Lubricator Kit 222345

910847
11
12
13
1
6
3
2
15 or 14
13
REF
02335
307843 41
Filter, Regulator, Lubricator Kit
Filter, Regulator, Lubricator (FRL) Kit 222345
FRL Kit 222345 (shown below) is available for Glutton pumps.
Ref.
No. Part No. Description Qty.
223004 Filter, Regulator Lubricator Assy
Includes items 1 to 7 1
1 106149 . Air Line Filter 1
2 104266 . Air Regulator 1
3 214848 . Lubricator 1
4 . Nipple 2
5 106145 . Bracket (not shown as not
used with this pump) 2
6 . U-Bolt 2
7 . Nut 4
Ref.
No. Part No. Description Qty.
8 101689 GAUGE, Air Pressure 1
9 183746 Bracket 1
10 183747 Bracket 1
11 100119 ELBOW, street 1
12 107142 VALVE, ball 1
13 218093 HOSE, coupled 1
14 155470 UNION, swivel, 90_ 1
15 222297 UNION, swivel, 45_ 1
