Parts Lists
3A9018A 7
Parts Lists
NOTE: Refer to manual 3A6417 for complete parts list. New parts are in bold for the models listed below.
California Proposition 65
Ref Part Description Qty
25U439 ENGINE, gas, 5.5 HP, Kohler 1
17E825K GMAX, 3400 std series
17E827K GMAX, 3900, std series
17E825KE GMAX, 3400 std series
17E827KE GMAX, 3900, std series
25U437 ENGINE, gas, 7.0 HP, Kohler 1
17E831K GMAX, 5900, std series
17E836K GMAX, 7900, std series
17E839K TexSpray, 5900 HD, std series
17E841K TexSpray, 900 HD, std series
25U457
ENGINE, gas, 7.0 HP, Kohler, EU
17E831KE GMAX, 5900, std series
17E836KE GMAX, 7900, std series
17E839KE TexSpray, 5900 HD, std series
17E841KE TexSpray, 900 HD, std series
 25U713 LABEL, safety, warning 1
17E825K GMAX, 3400 std series
17E827K GMAX, 3900, std series
17E831K GMAX, 5900, std series
17E836K GMAX, 7900, std series
17E839K TexSpray, 5900 HD, std series
17E841K TexSpray, 900 HD, std series
 17Z429 LABEL, safety, warning 1
17E827K GMAX, 3900, std series
17E831K GMAX, 5900, std series
17E836K GMAX, 7900, std series
17E839K TexSpray, 5900 HD, std series
17E841K TexSpray, 900 HD, std series
 17Z430 LABEL, safety, warning 1
17E825KE GMAX, 3400, std series
17E827KE GMAX, 3900, std series
17E831KE GMAX, 5900, std series
17E836KE GMAX, 7900, std series
17E839KE TexSpray, 5900 HD, std series
17E841KE TexSpray, 900 HD, std series
 25U714 LABEL, safety, warning 1
17E825KE GMAX, 3400 std series
17E827KE GMAX, 3900, std series
17E831KE GMAX, 5900, std series
17E836KE GMAX, 7900, std series
17E839KE TexSpray, 5900 HD, std series
17E841KE TexSpray, 900 HD, std series
 194126 LABEL, warning 1
 Replacement Danger and Warning Labels, Tags and
Cards are available at no cost.
Ref Part Description Qty
CALIFORNIA RESIDENTS
WARNING: Cancer and reproductive harm –
www.P65warnings.ca.gov.
