Graco GX21 User Manual

Setup
3A8429B 13
Battery Installation and Removal
Always start with a fully charged battery.
Do not splash or immerse battery or
charger in water. See battery and charger
information shipped with the sprayer.
Remove and install battery into the sprayer
as follows:
1. Remove the used battery, if in place.
2. Install battery by aligning the battery
pack with the rails inside the sprayer
and sliding it in until the battery pack is
firmly seated. Ensure that it does not
disengage.
Replace and charge battery only in a
well-ventilated area and away from
flammable or combustible materials,
including paints and solvents.

Graco GX21 Specifications

General

Maximum Operating Pressure	3300 psi
Hose Length	50 ft
Power Source	Electric
Max. Working Pressure	3300 psi
Type	Airless Paint Sprayer
Voltage	120V
Maximum Tip Size	0.021 inch
Motor	DC Motor
Flow Rate	0.31 GPM
Tip Size	0.021 in
