Technical Data
Category Data
Maximum fluid working pressure 3000 psi (21.0 MPa, 210 bar)
Fluid valve orifice size 0.188 in. (4.78 mm) diameter
Fluid inlet 1/4 npsm
Fluid outlet 1/4 npt
Wetted parts aluminum, tungsten carbide, stainless steel, zinc-plated steel,
PTFE, brass, Delrin
R
Length 8.125” (206 mm)
Height 5” (127 mm)
Weight 2 lb (0.9 kg)
Delrin
R
Manual Change Summary
This manual went from Rev. B to Rev. F (includes C, D, and E) to make the following changes:
D Ref. 15 (105–678, TRIGGER) was changed to 190–654, TRIGGER.
D Ref. 20 (168–846, GUARD, trigger) was changed to 192–165, GUARD, trigger.
D Ref. 26 (220–251, GUARD, tip) was changed to 222–674, GUARD, tip.
