Component Identification
8
Icons
Icon Function Shown on Screen(s)
General Icons
Confirm changes
• All
Exit without saving changes
• All
Next
• Setup screen #1
• Setup screen #3
• Run screen when Learn Mode is enabled
Previous
• Setup screen #1
• Run screen when Learn Mode is enabled
Learn Mode Active Indicator (shown in lower-left
corner)
• Run screen when Learn Mode is enabled
Setup Icons - see Controller Setup section on page 19
Reset Piston Counter to Zero
• Setup screen #1
Define Shot Amount
• Setup screen #2
Define Sequence Modes
• Setup screen #3
Open Gun Dispense Valve
• Setup screen #4
Close Gun Dispense Valve
• Setup screen #4
Change Password
• Setup screen #5
Enable “Tap” mode
• Setup screen #6
Enable “Hold” mode
• Setup screen #6
Enable “Initiate Shot” button on HMI
• Setup screen #7
Disable “Initiate Shot” button on HMI
• Setup screen #7
Enable Run Screen Shot Editing
• Setup screen #7
