Graco LD Series User Manual

Installation
313431A 7
Installation
The typical installations shown in FIG. 1 is only a guide
for selecting and installing a hose reel system. The com-
ponents shown are the minimum requirements for all
systems. However, it is not an actual system design.
Contact your Graco distributor for assistance in design-
ing a system to suit your needs.
NOTE: The air and fluid accessories required for your
pump must be properly sized to that pump. Refer to your
specific pump manual for selecting pump accessories.
Air Line Components
Install the following components in the order shown in
F
IG. 1, using adapters if necessary.
• Bleed-type Master Air Valve (E): locate down-
stream from the air regulator and for easy access
from the pump.
• Air Regulator (D): controls pump speed and outlet
pressure by adjusting the air pressure to the pump.
Locate the regulator close to the pump but upstream
from the bleed-type master air valve.
• Air Line Filter (C): removes harmful dirt and mois-
ture from the compressed air supply.
Fluid Line Components
Install the following components in the order shown in
F
IG. 1, using adapters if necessary.
• Fluid Drain Valve (H): install the drain valve point-
ing down but so the handle points up when the valve
is open.
• Fluid Shutoff Valve (J): shuts off fluid to hose reel.
• Dispensing Valve (N): dispenses the fluid or air.
Required Components
Be sure you have the following components before you
begin the installation.
• Hose inlet kit (L)
• Reel mounting bases, mounting brackets and
mounting channels (P)
• Dispense valves (N)
