Graco Line Driver 233725 Repair

30940414
Safety Interlock Wiring Diagram
(10) Switch under seat
(3) Engine
(37) Switch on Brake
Frame
198977
198976
198975
114956
ti1672a
Safety Interlock Test Procedure
The Line Driver safety Interlock prevents the engine from running if the parking brake is not set and the driver leaves
the seat. Periodically check the interlock.
1. Set parking brake.
2. Sit on Line Driver seat.
3. Start engine.
4. Release parking brake.
5. Get off the Line Driver seat.
6. If engine stalls, safety interlock operates correctly.
