List of Kits
30 332695C
List of Kits
Kit Number Models Kit Description
16G223 LTS 15 and LTS 17 Control Board Kit
16W944 ProLTS 19 Control Board Kit
122893 ProLTS 19 Fuse
16W949 LTS 15 Enclosure Kit
16W950 LTS 17 Enclosure Kit
16W942 ProLTS 19 Enclosure Kit
16W952 LTS 15 and LTS 17 Front Cover
16W945 ProLTS 19 Front Cover
247339 LTS 15 and LTS 17 Hose, 6.4mm x 7.5m, 6.4mm x 6.4mm fitting
247340 ProLTS 19 Hose 6.4mm x 15m, 6.4mm x 6.4mm fitting
257566 LTS 15 and LTS 17 Inlet Strainer
245673 ProLTS 19 Inlet Strainer
24K633 LTS 15 Left Leg
24K632 LTS 15 Right Leg
262014 LTS 17 and ProLTS 19 Left Leg
262012 LTS 17 and ProLTS 19 Right Leg
16X876 LTS 15 and LTS 17 Power Cord
16X877 ProLTS 19 Power Cord
289107 ProLTS 19 AutoPrime
246286 LTS 15, LTS 17, and ProLTS 19 Pressure Control 3000 psi
16E844 LTS 15 and LTS 17 Pump Inlet
288699 ProLTS 19 Pump Inlet
16E845 LTS 15 and LTS 17 Pump Outlet
243094 ProLTS 19 Pump Outlet
288747 ProLTS 19 Filter Kit (InstaClean™)
16F047 LTS 15 and LTS 17 Pump
288818 ProLTS 19 Pump
243011 LTS 15 and LTS 17 SG2 Gun
243012 ProLTS 19 SG3 Gun
197607 LTS 15 Suction Tube
16D951 LTS 17 Suction Tube
16H348 ProLTS 19 Suction Tube
244035 LTS 15, LTS 17, and ProLTS 19 Drain Tube Diffuser
235014 LTS 15, LTS 17, and ProLTS 19 Drain Valve
16G228 LTS 15 and LTS 17 Motor
256938 ProLTS 19 Motor
16E778 LTS 15 and LTS 17 Gear/Drive
289102 ProLTS 19 Gear/Drive
16G227 LTS 15 and LTS 17 Pump (Complete)
16X569 ProLTS 19 Pump (Complete)
256212 ProLTS 19 Lacquer Conversion Kit

Graco Magnum LTS 15 Specifications

General

Type	Airless Paint Sprayer
Maximum Tip Size	0.015 inches
Maximum Pressure	3000 psi
Power Source	Electric
Voltage	120V
Maximum Hose Length	75 feet
Flow Rate	0.27 GPM
Application	Interior and Exterior
Spray Tip	515
