Technical Data
46 332695C
Technical Data
LTS 15 LTS 17 ProLTS 19
Working pressure range 0-207 BAR, 0-21 Mpa (0-3000 psi)
Electric Motor 4.5A (open frame, universal) 6.5A (open frame, permanent
magnet DC)
Operating horsepower 1/2 5/8 7/8
Maximum delivery (with tip) 1.02 lpm (.27 gpm) 1.17 lpm (.31 gpm) 1.44 lpm (.38 gpm)
Paint hose 6.4mm X 7.5 m
(1/4 in. x 25 ft)
6.4mm X 15 m
(1/4 in. x 50 ft)
Maximum tip hole size 0.015 in (0.38 mm) 0.017 in (0.43 mm) 0.019 in (0.48 mm)
Weight, Sprayer only 5.4 kg (12 lb) 10.6 kg (23.3 lb) 15 kg (33.0 lb)
Weight, sprayer, hose, & gun 6.9 kg (15.2 lb) 12.1 kg (26.5 lb) 17.1 kg (37.7 lb)
Dimensions (Upright):
Length 36.8 cm (14.5 in) 49.0 cm (19.3 in) 54 cm (21.3 in)
Width 31.5 cm (12.4 in) 38.9 cm (15.3 in) 38.9 cm (15.3 in)
Height 45.5 cm (17.9 in) 94.0 cm (37.0 in) 93.2 cm (36.7 in)
Dimensions (Folded):
Length N/A 49.0 cm (19.3 in) 54 cm (21.3 in)
Width N/A 38.9 cm (15.3 in) 38.9 cm (15.3 in)
Height N/A 74.2 cm (29.2 in) 75.7 cm (29.8 in)
Power cord 1.0 mm², 3-wire, 1.8 m (6 ft)
Fluid inlet fitting 1/4 npsm external thread
Fluid outlet fitting 3/4 in. internally threaded
(standard garden hose)
7/8 - 14 UNF external thread
Inlet screen (on suction tube) 1190 micron (16 mesh) 1680 micron (12 mesh)
Generator requirement 1500 Watt minimum
Wetted parts, pump and hose stainless steel, zinc plated carbon steel,
brass, ultra-high molecular weight polyeth-
ylene (UHMWPE), Carbide, Nylon, Alumi-
num, PVC, polypropylene, fluroelastomer
stainless steel, zinc plated carbon
steel, brass, leather, ultra-high
molecular weight polyethylene
(UHMWPE), Carbide, Nylon,
Aluminum, PVC,
polypropylene, fluroelastomer
Wetted parts, gun aluminum, brass, carbide, nylon, ultra-high molecular weight polyethylene
(UHMWPE), zinc
Electrical power requirement 220-240V AC 50/60 Hz, I phase, 10A
Storage temperature range -35° to 71° C (-30° to 160° F)
Operating temperature range 4° to 46° C (40° to 115° F)
Noise *
Sound pressure 85 dBa
Sound power 95 dBa
When pump is stored with non-freezing fluid. Pump damage will occur if water or latex paint freezes in pump.
Damage to plastic parts may result if impact occurs in low temperature conditions.
Changes in paint viscosity at very low or very high temperatures can affect sprayer performance.
* Measured while spraying water-based paint, specific gravity 1.36, through a 517 tip at 207 bar, 20.7 MPa (3000
psi) per ISO 9614-2.
