Wiring Diagrams
44 332695C
Wiring Diagrams
Magnum LTS 15 and LTS 17
Models 16W120 and 16W121
ti22198b
Power Cord
Power Cord
Ref. EMI Filter
Ferrite Harness
Black Motor Lead
Black Motor Lead
Power Cord
Pressure Control
ON/OFF
Blue Wire
Switch
with White Heat Shrink
Green Wire
Brown Wire
