Wiring Diagrams
332695C 45
Magnum ProLTS 19
Model 16W122
ti22243b
Power Switch
Blue
Pressure
Brown Wire
Green/Yellow Wire
Motor
Brown Wire
AutoPrime
Wire
Control

Table of Contents

Other manuals for Graco MAGNUM LTS 17

Preview: Operation
Operation34 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Graco MAGNUM LTS 17 and is the answer not in the manual?

Graco MAGNUM LTS 17 Specifications

General IconGeneral
TypeAirless Paint Sprayer
Max Tip Size0.017 inches
Max Pressure3000 PSI
Hose Length50 feet
Weight20 lbs
Power SourceElectric
Motor Power5/8 HP
Spray Tip Size0.017 inches
