Component Identification
8 312667K
Component Identification
A Airless spray gun Sprays fluid.
B Power switch Turns sprayer ON and OFF.
C Pressure control knob
Increases (clockwise) and decreases (counter-clockwise) fluid pres-
sure in pump, hose, and spray gun.
C1 Setting Indicator
To select function, align symbol on pressure control knob with setting
indicator, page 11.
D Pump fluid outlet fitting Threaded connection for paint hose.
E
InstaClean
™
fluid filter
(ProX Sprayers Only)
• Filters fluid coming out of pump to reduce tip plugging and
improve finish.
• Self cleans only during pressure relief.
F
ProX Power-Piston
™
Pump (behind
Easy Access door, not shown)
(ProX Sprayers Only)
Pumps and pressurizes fluid and delivers it to paint hose.
F1
Easy Access
™
door
(ProX Sprayers Only)
Easy Access door permits quick access to outlet valve. To remove
door, insert flat blade of screwdriver into slot on the bottom of the
door (as shown on page 8).
G Suction tube Draws fluid from paint pail into pump.
H Prime tube (with diffuser) Drains fluid in system during priming and pressure relief.
J Prime/Spray valve
• In PRIME position (pointing down) directs fluid to prime tube.
• In SPRAY position (pointing forward) directs pressurized fluid to
paint hose.
• Automatically relieves system pressure in overpressure situa-
tions.
K
Storage compartment
(ProX Series A Sprayers Only)
Provides onboard storage for spray tips and/or tools.
L Inlet screen Prevents debris from entering pump.
M Paint hose Transports high-pressure fluid from pump to spray gun.
N
Fold-n-Store
™
Cart
(ProX Series A Sprayers Only)
Folding cart frame for hanging on wall.
Q Tip guard Reduces risk of fluid injection injury.
R Reversible spray tip
• Atomizes fluid being sprayed, forms spray pattern and controls
fluid flow according to hole size.
• Reverse unclogs plugged tips without disassembly.
S Gun trigger safety lever (page 11) Prevents accidental triggering of spray gun.
T Gun fluid inlet fitting Threaded connection for paint hose.
U Power Flush attachment
Connects garden hose to suction tube for power flushing water-base
fluids.
V Gun fluid filter Filters fluid entering spray gun to reduce tip clogs.
W
Hose wrap Rack
(X7, ProX7, and ProX9 Only)
Stows paint hose.
X
Pail hanger
(X7, Prox7, and ProX9 Only)
For transporting pail by its handle.
AA
QuickAccess
™
Inlet
(ProX9 Series A Only)
Permits quick access to inlet valve to clear debris.
