Component Identification X7 and ProX9
10 332689D
Component Identification X7 and ProX9
A Airless spray gun Dispenses fluid.
B Power switch Turns sprayer ON and OFF.
C Pressure control knob Increases (clockwise) and decreases (counter-clockwise) fluid pressure in pump,
hose, and spray gun.
C1 Setting Indicator To select function, align symbol on pressure control knob with setting
indicator, page 13.
D Pump fluid outlet fitting Threaded connection for paint hose.
E InstaClean™ fluid filter
(ProX9 Sprayer Only)
Filters fluid coming out of pump to reduce tip plugging and improve
finish.
Self cleans only during pressure relief.
F Power-Piston™ Pump (behind
Easy Access door, not shown)
(ProX9 Sprayer Only)
Pumps and pressurizes fluid and delivers it to paint hose.
F1 Easy Access door
(ProX9 Sprayer Only)
Easy Access door permits quick access to outlet valve. To remove door, insert flat
blade of screwdriver into slot on the bottom of the door (as shown on page, 11).
G Suction tube Draws fluid from paint pail into pump.
H Prime tube (with diffuser) Drains fluid in system during priming and pressure relief.
J Prime/Spray valve
PRIME position directs fluid to prime tube.
SPRAY position directs pressurized fluid to paint hose.
Automatically relieves system pressure in overpressure situations.
K Autoprime
(ProX9 Sprayer Only)
Automatically taps the inlet ball when you turn the sprayer on.
L Inlet screen Prevents debris from entering pump.
M Paint hose Transports high-pressure fluid from pump to spray gun.
Q Tip guard Reduces risk of fluid injection injury.
R Reversible spray tip
Atomizes fluid being sprayed, forms spray pattern and controls fluid flow
according to hole size.
Reverse unclogs plugged tips without disassembly.
S Gun trigger safety lever
(page 13)
Prevents accidental triggering of spray gun.
T Gun fluid inlet fitting Threaded connection for paint hose.
U Power Flush attachment Connects garden hose to suction tube for power flushing water-base
fluids.
V Gun fluid filter Filters fluid entering spray gun to reduce tip clogs.
W Hose wrap Rack Stows paint hose.
X Pail hanger For transporting pail by its handle.
Y Power Cord Supplies sprayer with electricity.
Z Power Flush Adapter
(ProX9 Sprayer Only)
Adapts suction tube (G) to Power Flush attachment (U).
AA Pump Priming Button
(X7 Sprayer Only)
Manually taps inlet ball to loosen if stuck.
AB Plug Adapter Adapts power cord to Australian electrical outlet.
AC Plug Adapter Retainer Retains plug adapter to power cord.

Other manuals for Graco Magnum X7

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Graco Magnum X7 and is the answer not in the manual?

Graco Magnum X7 Specifications

General IconGeneral
TypeAirless Paint Sprayer
Maximum Pressure3000 PSI
Maximum Hose Length100 ft
Maximum Tip Size0.017 in
Flow Rate0.31 GPM
Hose Length25 ft
Power SourceElectric
Voltage120V
Recommended Annual UseUp to 125 gallons per year
