Storage
26 332689D
5. When storage fluid comes out of prime tube (5-10
seconds) turn power switch OFF.
6. Move Prime/Spray valve to SPRAY to keep storage
fluid in sprayer during storage.
Stowing Sprayer
1. Screw inlet screen onto suction tube.
2. Coil hose. Leave it connected to sprayer. Wrap
hose around hose wrap bracket or sprayer stand.
3. Secure a plastic bag around suction tube to catch
any drips.
4. Store sprayer indoors.
ti2018a
ti9345a
NOTICE
• Before storing sprayer make sure all water is
drained out of sprayer and hoses.
• Do not allow water to freeze in sprayer or hose.
• Do not store sprayer under pressure.
ti9433a
ti12947a
ti22184a
ti5552a

Graco Magnum X7 Specifications

General

Type	Airless Paint Sprayer
Maximum Pressure	3000 PSI
Maximum Hose Length	100 ft
Maximum Tip Size	0.017 in
Flow Rate	0.31 GPM
Hose Length	25 ft
Power Source	Electric
Voltage	120V
Recommended Annual Use	Up to 125 gallons per year
