Wiring Diagrams
3A2244A 35
Mark X Units:
Pressure
Transducer
Potentiometer
Digital Display
10A - 16A Switch
ON/OFF
Switch
Power Plug
green/ground
Motor
Leads
Motor Sensor Leads
Thermal
Switch
Motor
Filter
Board
ti18684a
