Graco NAUTILUS SNUGLOCK LX - Page 50

50
3 Forward
Facing
6A. Open the SnugLock
®
Lock-Off
Push the bottom of the release, then pull
the top of the tab out. Open the SnugLock
®
Lock-Off.
E. Pull down the lower backrest pad to
expose the SnugLock
®
Lock-Off.
E
8A. Tighten the Vehicle Seat Belt
Press down firmly on the top of the base
while pulling on the shoulder belt to remove
the slack.
Do not pull on the strap with excessive
force.
