Graco NAUTILUS SNUGLOCK LX User Manual

7
Adult Assembly Required
1. Raise Seat Back
Grab seat pad fabric in sitting area to
expose the gutters.
Make Sure all hands, fingers and other
objects are clear of the gutters.
Make Sure the harness straps are securely
attached within the “T”-shaped slots around
the arms as shown.
With your other hand, raise seat back so
that both arms LOCK into the gutters. Arms
should click into the gutters. Seat assembly
should appear as shown.
Harness
Strap
T-Slot
Arm
Attach Headrest
Squeeze height adjust button and push headrest into
slots on the back support as shown. Headrest will
click into the back support.
You may need to unfasten the hook and loop
attachment tape on both sides at the top of the
back support to allow for easier access to the slots.
Always use child restraint with headrest installed
and properly adjusted.
Click!
Car Seat Assembly (On Select Models)
(Follow the directions that matches your model)
