4 Booster
69
4-C Install Backless Booster
1. Remove the Seat Back
A. With the harness system loose, from the
back of the seat, remove the harness
straps from the splitter plate as shown.
B. Unsnap seat base pad and pull forward
to expose the
seat base.
Undo elastic
straps on
select models.
