4 Booster
70
C. Push the buckle through the pad and
store.
D. Release the back support by pulling the
seat base pad forward to expose the seat
base. Slide the 2 buttons towards the
seat back and lower the seat back into a
flat position.
E. Squeeze the 2 buttons together and slide
backrest out of the base.
F. Store the splitter plate on the base of the
seat.
G. Pull on the adjustment strap on the front
of the seat to lock the splitter plate into
place.
