Graco ProMix Easy Installation

309623F 11
Selection c: Enter Pump Size
Note: Pump values shown here
for selections c, d, and e are for
Ultra Mix pump, see table on
page 9 for other pumps
Selection d: Enter Pump
Length
Selection e: Enter Pump
Offset
Note: FIG. 10 on the next page
shows a sample offset and
changeover.
Selection f: Enter Flow Meter
Calibration
Enter Selection [a-g]: c
Enter new pump size (cc/cycle). Current = 54
? 54
Pump size (cc/cycle) = 54.
Enter Selection [a-g]: d
Enter new pump length (x1000 inch/cycle). Current = 6000
? 6000
Pump length (x1000 inch/cycle) = 6000.
Enter Selection [a-g]: e
Enter new pumpOffset (x1000 inch). Current = 150
? 150 (for UltraMix-based system)
? 300 (for HydraMix-based system)
Enter new TopChangeOver Zone (x1000 inch). Current = 150
? 150 (for UltraMix-based system)
? 500 (for HydraMix-based system)
Enter new BottomChangeOver Zone (x1000 inch). Current = 150
? 150 (for UltraMix-based system)
? 700 (for HydraMix-based system)
Pump Offset = 150. TopChangeOver Zone = 150. BottomChangeOver Zone = 150.
(for UltraMix-based system)
Pump Offset = 300. TopChangeOver Zone = 500. BottomChangeOver Zone = 700.
(for HydraMix-based system)
Enter Selection [a-g]: f
Enter new flow meter A k-factor (x1000 cc/pulse). Current = 119
? 119
Enter new flow meter B k-factor (x1000 cc/pulse). Current = 119
? 119
Enter new ratio balance (1-99%). Current = 5
? 5
k-factor A = 119. k-factor B = 119. Ratio tolerance = 5.
