Graco PT2500 - Page 23

 
Parts
Ref.
No.
Part No. Description Qty.
10 105–659 T
OGGLE BOOT 1
11 105–679 SWITCH, toggle 1
12 112–608 PLA
TE, switch, ON/OFF 1
15 106–013
STRAIN RELIEF BUSHING 1
18a 110–900 .STAR
TER SWITCH 1
20 180–406
HOUSING, diaphragm 1
21 218–727
DIAPHRAGM ASSEMBL Y 1
22 224–624
PUMP HOUSING KIT
Includes 22a, 22b 1
22a 187–185
GUIDE, diaphragm 1
22b 187–339
HOUSING, pump 1
24 109–042 W
ASHER, spring, rib 4
25 107–514 CAPSCREW
, hex head,
M8 x 1.25 mm 4
26 218–726 VAL
VE, inlet check
Includes replaceable item 26a 1
26a 180–446 .GASKET 1
28 236–954 OUTLET CHECK V AL VE ASSY
Includes items 28a–28f 1
28a 180–455 .SEAL, washer 1
28b 218–968 .HOUSING, seat, valve 1
28c 112–619 .SPRING, compression 1
28d 218–505
.PLUG, ball stop 1
28e 1 12–618 .BALL, carbide 1
28f 180–454 .W ASHER 1
10
12
11
15
Ref 17
DET AIL B
BLACK
WHITE
GREEN
18a


The
starter
switch
is located in this
box.

20
21
22a
22b
26a
26
24
25
28a
28b
28c
28f
28d
DETAIL A





Lubricate the threads.
T orque to 14–17 N.m.
T orque to 32–34 N.m.
T orque to 19–23 N.m.
T orque to 36–41 N.m.
Do not alter the position of the nut.





28e



