Repair

Replace Replace

Replace

Belt Belt

Belt

1.FollowShutdown,page49.

2.Removetheheatercover(134)andthebelt

coverfasteners(19).

NOTICE NOTICE

NOTICE

Topreventdamagetotheovertemperature

switch,carefullyremovethecovers.

3.Liftcover(132)andloosenthebluebracket(131)

fasteners.Liftthebluebracket(133)offofthe

fastenersandsetaside.Removethebeltcovers

(131,132).

4.Removethebelt.

5.Installthenewbeltandreplacethecovers.

56 334946C
