Graco REACTOR E-20 - Page 58

Reactor Assembly
58 309574L
Reactor Assembly Parts Continued
* Uses 1.6Amp, Slo-Blow Fuse 120614. This fuse must be
slow blow for In-rush Current Limiter to function properly.
▲ Additional warning labels are available at no cost.
Ref.
No. Description
Reactor Models
Qty
248657
E-30
w/15.3
kW
248658
E-30
w/15.3
kW
248659
E-30
w/15.3
kW
2 HEATER; pages
59, 35
245963 24962 245962 2
3 MODULE, pro-
portioner; page
61
245957 245957 245957 1
6 CONTROL,
motor; page 65
245981 245981 245981 1
8 TRANSFORMER; 15B352 15B352 15B352 1
9 SHIELD 276879 276879 276879 1
14 TUBE, heater,
component A
15B685 15B685 15B685 1
15 TUBE, pump,
component A
15B686 15B686 15B686 1
16 TUBE, heater,
component B
15B687 15B687 15B687 1
17 TUBE, pump,
component B
15B688 15B688 15B688 1
21 CONNECTOR,
tube
117594 117594 117594 2
28 MODULE,
breaker; page 68
246090 246089 246098 1
36 SWITCH, added
pole; 380V
117553 1
39 FILTER; 230V 117667 117667 117667 1
51▲
LABEL, warning
198278 198278 198278
1
52 CABLE, harness,
filter
15B385 15B385 15B385 1
65 ELBOW, swivel;
3/4 npt(m) x 3/4
npt(f)
ELBOW, swivel;
3/4 npt(m) x 1”
npt(f)
118463 118463 118463 2
71 SCREW, machine 104590 104590 104590 2
72 BRACKET, heater
BRACKET, heater 15C733 15C733 15C733 2
73 WASHER, lock 103181 103181 103181 2
76 CAPACITOR 244733 244733 244733 1
77 BRACKET 197999 197999 197999 1
86 CABLE, overtem-
perature, jumper;
see pages 59, 60)
CABLE, overtem-
perature, jumper;
see page 60)
15B769 15B769 15B769 4
92 CABLE, harness,
power; see pages
68-70
CABLE, harness,
power; see pages
68-70
15B382 15B382 15B382 1
95 BOLT; hex hd;
3/8-16
BOLT; hex hd;
3/8-16
516595 516595 516595 4
96 LOCKWASHER;
3/8
LOCKWASHER;
3/8
100133 100133 100133 4
97 NUT, channel
NUT, channel 118446 118446 118446 4
102 STRAP, motor 15B108 15B108 15B108 1
121 LABEL 15B538 15B538 15B538 1
122* In-rush Current
Limiter; page 54
288359 1
Ref.
No. Description
Reactor Models
Qty
248657
E-30
w/15.3
kW
248658
E-30
w/15.3
kW
248659
E-30
w/15.3
kW
