Graco Reactor E-30 Series Electrical Diagrams

Models
312067H 3
Models
E-20 SERIES
E-30 SERIES
E-XP1 SERIES
E-XP2 SERIES
* Full load amps with all devices operating at maximum capabilities. Fuse requirements at various flow rates and mix
chamber sizes may be less.
† Total system watts, based on maximum hose length for each unit:
• E-20 and E-XP1 series, 210 ft (64 m) maximum heated hose length, including whip hose.
• E-30 and E-XP2 series, 310 ft (94.5 m) maximum heated hose length, including whip hose.
 Maximum flow rate given for 60 Hz operation. For 50 Hz operation, maximum flow rate is 5/6 of 60 Hz maximum
flow.
Part, Series
Full Load Peak
Amps*
Nominal Voltage
Range (phase)
System
Watts†
Primary
Heater
Watts
Max Flow
Rate
lb/min
(kg/min)
Approximate
Output per Cycle
(A+B)
gal. (liter)
Maximum Fluid
Working Pressure
psi (MPa, bar)
259025, G 48 200-240 V (1) 10,200 6,000 20 (9) 0.0104 (0.0395) 2000 (14, 140)
259030, G 24 350-415 V (3) 10,200 6,000 20 (9) 0.0104 (0.0395) 2000 (14, 140)
259034, G 32 200-240 V (3) 10,200 6,000 20 (9) 0.0104 (0.0395) 2000 (14, 140)
Part, Series
Full Load Peak
Amps*
Nominal Voltage
Range (phase)
System
Watts†
Primary
Heater
Watts
Max Flow
Rate
lb/min
(kg/min)
Approximate
Output per Cycle
(A+B)
gal. (liter)
Maximum Fluid
Working Pressure
psi (MPa, bar)
259026, F 78 200-240 V (1) 17,900 10,200 30 (13.5) 0.0272 (0.1034) 2000 (14, 140)
259031, F 34 350-415 V (3) 17,900 10,200 30 (13.5) 0.0272 (0.1034) 2000 (14, 140)
259035, F 50 200-240 V (3) 17,900 10,200 30 (13.5) 0.0272 (0.1034) 2000 (14, 140)
259057, F 100 200-240 V (1) 23,000 15,300 30 (13.5) 0.0272 (0.1034) 2000 (14, 140)
259058, F 62 200-240 V (3) 23,000 15,300 30 (13.5) 0.0272 (0.1034) 2000 (14, 140)
259059, F 35 350-415 V (3) 23,000 15,300 30 (13.5) 0.0272 (0.1034) 2000 (14, 140)
Part, Series
Full Load Peak
Amps*
Nominal Voltage
Range (phase)
System
Watts†
Primary
Heater
Watts
Max Flow
Rate
gpm (lpm)
Approximate
Output per Cycle
(A+B)
gal. (liter)
Maximum Fluid
Working Pressure
psi (MPa, bar)
259024, G 69 200-240 V (1) 15,800 10,200 1.0 (3.8) 0.0104 (0.0395) 2500 (17.2, 172)
259029, G 24 350-415 V (3) 15,800 10,200 1.0 (3.8) 0.0104 (0.0395) 2500 (17.2, 172)
259033, G 43 200-240 V (3) 15,800 10,200 1.0 (3.8) 0.0104 (0.0395) 2500 (17.2, 172)
Part, Series
Full Load Peak
Amps*
Nominal Voltage
Range (phase)
System
Watts†
Primary
Heater
Watts
Max Flow
Rate
gpm (lpm)
Approximate
Output per Cycle
(A+B)
gal. (liter)
Maximum Fluid
Working Pressure
psi (MPa, bar)
259028, F 100 200-240 V (1) 23,000 15,300 2.0 (7.6) 0.0203 (0.0771) 3500 (24.1, 241)
259032, F 35 350-415 V (3) 23,000 15,300 2.0 (7.6) 0.0203 (0.0771) 3500 (24.1, 241)
259036, F 62 200-240 V (3) 23,000 15,300 2.0 (7.6) 0.0203 (0.0771) 3500 (24.1, 241)
