Graco REACTOR E-XP1

Repair
309574L 35
F
IG. 10. Motor Control Board
1
Apply 110009 thermal heatsink
compound to mating surfaces.
1
TI2576A-1
TI3153A-1
245980 Motor Control, for E-20 and E-XP1
245981 Motor Control, for E-30 and E-XP2
J3 (A)
J8 (B)
J1
J4
J7
J13
J10
L
J1
J6
J13
J7
J3 (B)
J5 (A)
1
D11
D7
J12
J12
SW2
SW2
N
DIP Switch (SW2) Settings
TI3178b-2
TI3178b-1
Model E-XP2
Model E-30
DIP Switch (SW2) Settings
Model E-20
Model E-XP1
TI3178b-3
TI3178b-4
