Graco Reactor H-25 Series Repair And Parts

Parts
312063Z 69
Circuit Breaker Modules Parts List
* 8 kW H-25 models only.
† 15.3 kW H-25, H-XP2, H-40, H-50 models only.
 12kW H-40, H-50 models only.
Ref. Description
Breaker Modules
Qty.
A
230V, 3 phase
B
400V, 3 phase
C
230V, 1 phase
D
230V, 3 phase
E
400V, 3 phase
801 RAIL, mounting
255028 255028 255028 255028 255028 1
802 CLAMP, block, end
255045 255045 255045 255045 255045 1
803 HOLDER, fuse terminal, block
255043 255043 255043 255043 255043 2
804 FUSE
255023 255023 255023 255023 255023 2
805 TERMINAL, block
255042 255042 255042 255042 255042 4
807 BRIDGE, plug in, jumper
255044 255044 255044 255044 255044 2
808 BLOCK, terminal ground
255046 255046 255046 255046 255046 1
809 BREAKER, 1 pole, 50A
255026 255026 255026 255026 255026 1
810 CONTACTOR, relay, 65A
255022 255022 255022 1
CONTACTOR, relay, 65A
255022 255022 2
811 BREAKER, 2 phase, 40A
247768 247768 247768 247768 247768 1
812 BREAKER, 2 phase, 25A
*255050 *255050 *255050 2
BREAKER, 2 phase, 40A
†247768 †247768 †247768 2
BREAKER, 2 phase, 50A
120579 120579 2
813 BREAKER, 2 phase, 20A
255049 255049 *†255049 1
BREAKER, 3 pole, 20A
255025 255025 1
BREAKER, 2 phase, 30A
255041 1
814 CONNECTOR, power lug
117679 117679 3
CONNECTOR, power lug
117679 2
815 BAR, power buss, 3 phase
117805 1
BAR, power buss, 1 phase
117678 1
BAR, power buss, 3 phase, 3x3
255024 1
816 CABLE, harness lower
247802 247802 247802 247803 247803 1
817 CABLE, harness upper
247805 247806 247804 247808 247807 1
818 CONNECTOR, 2 pin large
255027 255027 255027 255027 255027 3
819 CONNECTOR, 3 pin
120895 120895 120895 120895 120895 1
820 CONNECTOR, 4 pin
255031 255031 255031 255031 255031 1
821 CONNECTOR, 2 pin small
255030 255030 1
822 CABLE, harness, hose wire
247791 247791 247791 247791 247791 1
