Graco SnugRide SnugLock 30 User Manual

6 Vehicle
Information
68
Locking Latch Plate and
ELR Retractor
A latch plate that holds
the lap belt snug after
it has been adjusted;
contains a metal bar
on the underside of the
hardware that “locks” the
belt in position.
When installing the car
seat, route the vehicle
seat belt through the
proper belt path and
buckle it in. Then, pull
upwards on the shoulder
belt so that the lap belt
gets tight around the
base or car seat.
Grab the sides of the
base or seat at the belt
path and slide side to
side and front to back.
The base or seat should
not move more than 2.5
cm (1 in).
Note: When using the base, remove
all the slack from the seat belt. The
lock-off locks the seat belt.

Graco SnugRide SnugLock 30 Specifications

General

Weight Capacity	4-30 lbs
Height Capacity	Up to 30 inches
Harness Type	5-point harness
Compatibility	Compatible with Graco Click Connect strollers
Expiration	7 years from manufacture date
Installation	SnugLock Technology
Base	Includes SnugLock base
Safety Features	Side-impact tested
