6 Vehicle
Information
69
Sliding Latch Plate and
ALR Retractor
A latch plate that
slides freely on the belt
webbing and cannot, by
itself, hold the belt snug
around a car seat.
Slowly pull the
shoulder belt all the
way out. Route the
vehicle seat belt through
the proper belt path and
buckle it in. Then, as you
pull the vehicle seat belt
tight, feed all the slack
back into the retractor.
Grab the sides of the
base or seat at the belt
path and slide side-to-
side and front-to-back.
The base or seat should
not move more than 2.5
cm (1 in).

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Graco SnugRide SnugLock 30 and is the answer not in the manual?

Graco SnugRide SnugLock 30 Specifications

General IconGeneral
Weight Capacity4-30 lbs
Height CapacityUp to 30 inches
Harness Type5-point harness
CompatibilityCompatible with Graco Click Connect strollers
Expiration7 years from manufacture date
InstallationSnugLock Technology
BaseIncludes SnugLock base
Safety FeaturesSide-impact tested
