Graco ULTRA MAX 695 Instructions-Parts List

6 309067
Basic Problem Solving
TYPE OF
PROBLEM
WHAT TO CHECK
If check is OK, go to next check
WHAT TO DO
When check is not OK, refer to this column
11. Motor thermal cutout switch. Connect ohmmeter between
motor yellow leads. Meter must read 1 ohm maximum.
11. Allow motor to cool. Correct cause of
overheating. If switch remains open after
motor cools, replace motor.
12. Pressure transducer (67) by replacing it with a new one. 12. Replace pressure transducer.
See page 16.
13. Pressure adjustment potentiometer (77) by replacing it
with a new one.
13. Replace potentiometer. See page 14.
Intermediate Problem Solving
TYPE OF
PROBLEM
WHAT TO CHECK
If check is OK, go to next check
WHAT TO DO
When check is not OK refer to this column
Low output 1. For worn spray tip. 1. Follow Pressure Relief Procedure
Warning on page 3, then replace tip.
See your separate gun or tip manual.
2. Verify pump does not continue to stroke when gun trigger
is released. Plug in and turn on sprayer. Prime with paint.
Trigger gun momentarily, then release and engage safety
latch. Relieve pressure, turn off and unplug sprayer.
2. Service pump. See page 11.
3. Release gun trigger. Observe resting position of pump rod
(222).
3. If pump consistently comes to rest
with rod (222) fully extended, the piston
packings and/or piston valve may be
worn. Service pump. See page 11.
4. Electrical supply with volt meter.
Meter must read 90–110 VAC for 232916, 232917.
Meter must read 105–125 VAC for 232910 – 232913,
232919
Meter must read 210–250 VAC for 232918, 232915,
232914.
4. Reset building circuit breaker; replace
building fuse. Repair electrical outlet or
try another outlet.
5. Extension cord size and length; must be at least 12 AWG
(1.5 mm
2
) and no longer than 300 ft (90 m).
5. Replace with a correct, grounded exten-
sion cord.
6. Motor brushes. See Electrical – What To Check, item 4, on
page 5.
6. See page 10.
Low output
(continued)
7. Motor control board (22a) by substituting with a good
board.
CAUTION: Do not perform this check until motor armature
is determined to be good. A bad motor armature can burn
out a good board.
7. Replace board. See page 13.
8. Motor armature for shorts by using an armature tester
(growler) or perform motor test. See page 9.
8. Replace motor. See page 12
.

Graco ULTRA MAX 695 Specifications

General

Maximum Flow Rate	0.95 GPM
Maximum Operating Pressure	3300 PSI
Hose Length	50 ft
Maximum Pressure	3300 PSI
Power Source	Electric
Material	Stainless Steel
Motor Power	2.0 hp Brushless DC
