On/Off Switch Replacement
309674M 25
Wiring Diagram
02725
WLD
ON/OFF Switch
Ground
Black
Ref 30
Power Plug
Ref 56
White
Black
Pressure Transducer
Ref 38
Potentiometer
Ref 37
J11
J12
Black
Green
210
211
