Technical Data
309674M 31
Technical Data
Basic Sprayer Wetted Parts:
zinc-plated carbon steel, nylon, stainless steel, PTFE, acetal, chrome plating, leather, UHMWPE, aluminum,
tungsten carbide
Noise Level:
Sound power . . . . . . . . . . 100 dBa*
Sound pressure . . . . . . . . . 90 dBa*
*Measured 3 feet (1 meter) from equipment.
Dimensions
Model
100-120V
Ø, A, Hz
220-240 V
Ø, A, Hz
Generator
Minimum W
Motor HP
(W)
Cycles/
Gal (l)
Max
Delivery
gpm (lpm)
Max Tip
Size
Fluid
Outlet
npsm
395 1, 11, 50/60 1, 7, 50/60 3000 3/4 (560) 700 (185) 0.50 (1.9) 0.023 1/4 in.
490 1, 12, 50/60 1, 6, 50/60 3500 7/10 (510) 620 (165) 0.54 (2.0) 0.023 1/4 in.
495 1, 13, 50/60 1, 7, 50/60 3750 3/4 (560) 620 (165) 0.60 (2.3) 0.025 1/4 in.
595 1, 15, 50/60 1, 7, 50/60 4000 9/10 (671) 540 (143) 0.68 (2.6) 0.027 1/4 in.
Model
Weight lb (kg)
Height in.
(cm)
Length in.
(cm)
Width in.
(cm)
Ultra 395 UltraMax II
490
Ultra 495 UltraMax II
495
Ultra 595 UltraMax II
595
Stand 43 (20) 34 (19) 43 (20) 34 (19) N/A N/A 21 (53.3) 15 (38.1) 14 (35.6)
Lo-Boy 63 (29) 54 (25) 63 (29) 54 (25) 69 (31) 69 (31) 21 (53.3) 26 (66.0) 20.5 (52.1)
Hi-Boy 66 (30) 57 (26) 66 (30) 57 (26) 72 (33) 72 (33)
Handle down:
29.5 (74.9)
Handle Up:
39.5 (100.3)
21 (53.3) 20.5 (52.1)
