Graco XM Series

Troubleshooting
72 312359R
Alarm And Advisory Code Key
Use the following table as a quick guide to determine alarm codes.
EVENT MODE LOCATION ZONE
A Current 1 Low Alarm A Material A 1 Tank A
F Flow 2 Low Deviation B Material B 2 Tank B
L Tank Level 3 High Deviation C Controller A Heater A
P Pressure 4 High Alarm D Output Discharge B Heater B
R Ratio 5 Calibration F Input Feed C Level Sensor A
T Temperature 6 Sensor Failure M Pneumatic Supply D Level Sensor B
V Voltage 7 Unexpected Non-Zero Value P Pneumatic Supply E Hose
8 Unexpected Zero Value R Recirculation H Heater Hose
9 Unstable J Linear Sensor
C Communication A Loss K Reed Switch
D Pump A Runaway P Display
D Cavitation X System
E Time-out
F Stall Up
G Stall Down
J Linear Sensor
K Reed Switch
M Maintenance A Pump
E Valve
G Filter
Q Proportioning D Overdose
P Potlife
T Dosing Time
