Graco XM Series

Component Identification
312359R 21
Fluid Control Assembly
AA Dosing Valve A
AB Dosing Valve B
AC Recirculation Valve A
AD Recirculation Valve B
AE Sampling Valve A
AF Sampling Valve B
AG Restriction Valve
AH Mix Manifold Shutoff / Check Valve A
AJ Mix Manifold Shutoff / Check Valve B
AK Solvent Shutoff Valve
AL Pressure Sensor
AM Solvent Check Valve
FIG. 3: Fluid Control Assembly
AB
AD
AF
AG
AJ
AK
AA
AE
AH
AL
AM
AC
