Dimensions
312359R 97
XM System Dimensions without Hoppers (Hazardous Locations)
B
D
C
A
Ref. Dimensions
A 39.5 in. 100.3 cm
B 36.0 in. 91.4 cm
C 79.0 in. 200.6 cm
D 38.0 in. 96.5 cm
